G2895TP1U
Dual Channel Power Distribution Switches
The G2895 is a tiny dual channel integrated power switches for high-side power protection switch application.
檔案下載
規格表
|
Vin (V)
|
min.
|
2.7 |
|---|---|---|
|
max.
|
5.5 | |
|
RON
|
(mΩ)
|
120 |
|
VOUT Rising
|
(ms)
|
2 |
|
IOUT (A)
|
0.2/0.6 | |
|
OC Flag
|
N/Y | |
|
Dis-R (Ω)
|
150 | |
|
Note
|
Vin Range 2.7V~5.5V with a VB of 3V/5VRecovery Mode & Latched Mode | |
|
Package
|
TSOT-23-6 | |
|
Datasheet
|
EDS-2895-1555-190422-0.4.pdf | |
