G1224P8U
Dual Rail-to-Rail I/O, High-Slew-Rate OP Amp
G1224 is a input/output rail-to-rail Operational Amplifier. It can be operated from +2.2V to +5.5V single supply or from ±1.1V to ±2.75 dual supply. G1224 can drive 66mA into resistor loads to within 10% power rail each amplifier. AC performance is very excellent with 6MHz bandwidth, 6V/µs Slew Rate, 95dB open loop gain, 60 degree phase margin and low distortion.
檔案下載
規格表
|
VDD (V)
|
min.
|
2.2 |
|---|---|---|
|
max.
|
5.5 | |
|
CH
|
2 | |
|
IOUT
|
(mA)
|
66 |
|
S/R
|
(V/µs)
|
6 |
|
BW
|
(M Hz)
|
2.5 |
|
Offset
|
(mV)
|
5 |
|
Note
|
Rail-to-Rail Input/Output | |
|
Package
|
MSOP-8 | |
|
Datasheet
|
EDS-1224-104-1.8-100630.pdf | |
