G948C6A10T11G
600mA Low-Dropout Linear Regulators
The G948C6 is a low-supply current, low-dropout linear regulator. An over-temperature protection circuit is built-in in the G948C6 to prevent thermal overload. These power-saving features make the G948C6 ideal for use in a battery-powered application such as notebook computers, and portable devices.
Downloads
Specifications
|
Vin (V)
|
min.
|
2.5 |
|---|---|---|
|
max.
|
6 | |
|
IOUT
|
(A)
|
0.6 |
|
VOUT
|
(V)
|
VSET=1V |
|
Dropout
|
(V)
|
0.42 |
|
EN
|
Y | |
|
Dis-charge
|
(Ω)
|
100 |
|
IQ
|
(µA)
|
60 |
|
Note
|
MLCC | |
|
Package
|
SOT-23-5 | |
|
Datasheet
|
EDS-948C6-1791-240417-0.2.pdf | |
