G2230ABZ1U

The G2230A provides switch-mode Li-ion charger with dynamic power path control. The device supports USB input sources, including standard USB host port and USB charging port, and detects the input source through D+/D- detection following the USB battery charging revision 1.2. In addition, the G2230A detects non-standard 2A/1A adapters. The G2230A also supports USB OTG operation by supplying default 5V on the DCIN with a programmable current limit (1.5A/2.0A). The G2230A supports Power Bank Mode operation by supplying 5.2V on the PMID pin. Meanwhile, the G2230A includes Power key function to manage the power on/off control through PWRON signal.
